The backpack projector. Main goal of this project was the development of a maximum
performance, minimum size white light projector. The footprint of this device is less than
DIN A4 (295mm x 205mm) with a height of 115mm.
10/100 MBit Ethernet, DMX512 in/thru, a local DMX512 output and a fully implemented
RS232 interface can be used for communication. A universal switching power supply with
sequencing allows connection to any mains. A fast condenser battery with charging circuitry
provides additional buffering of driver peaks to gain higher scanner acceleration.
Horizon DPW-600/LT: 600mW white (445nm, 532nm, 650nm), ScanMaster3 projector control
board, SmartMove digital drivers, CTI 6210 scanners.
